Description
xVictron Orion 12/24-8 Non-Isolated DC-DC Converter IP20
The Victron Orion 12/24-8 is a non-isolated DC-DC converter that steps up a 12V input to a 24V output at up to 8A continuous current. It is designed for mobile, marine and off-grid applications where a stable 24V supply is needed from a 12V battery source. The IP20 rating makes it suitable for installation in enclosed, protected enclosures.
Key Features
- Converts 12V DC input to 24V DC output at up to 8A continuous output current.
- Non-isolated design provides efficient voltage step-up without galvanic isolation between input and output.
- IP20 protection rating, suitable for installation inside cabinets, panels or enclosed spaces.
- Compact and lightweight at 182g, making it practical for space-constrained installations.
- Part of the Victron Orion DC-DC converter range, compatible with Victron system architectures.
- SKU: ORI122408020 | GTIN: 8719076022732
Product Overview
The Orion 12/24-8 steps up a nominal 12V battery supply to 24V at 8A, delivering up to 192W of converted power. This is useful in vehicles, boats or off-grid enclosures where a 24V load (such as a motor, lighting circuit or auxiliary device) must be powered from a 12V battery bank without running a separate 24V battery system.
The non-isolated topology means the input and output share a common ground reference. This is an important consideration during system design: non-isolated converters are efficient and cost-effective, but they are not suitable where galvanic isolation between circuits is required. For applications requiring isolation, Victron's isolated Orion-Tr range should be used instead.
The IP20 enclosure rating protects against solid objects larger than 12.5mm but provides no protection against moisture or liquids. Installation must be in a dry, enclosed location such as a switchboard, control cabinet or battery compartment with adequate ventilation.
Specifications
- SKU: ORI122408020
- Input voltage: 12V nominal
- Output voltage: 24V
- Output current: 8A
- Type: Non-isolated DC-DC converter
- IP rating: IP20
- Weight: 0.182 kg
- GTIN: 8719076022732
Applications
- Powering 24V auxiliary loads from a 12V vehicle or marine battery bank.
- Off-grid cabins or enclosures where a single 12V battery system must supply a 24V circuit.
- Mobile installations such as campervans, motorhomes or commercial vehicles with mixed-voltage requirements.
- Industrial control panels requiring a 24V supply derived from a 12V source.
- Boat electrical systems where a 24V instrument or motor circuit is fed from a 12V house bank.
What Is Included
- 1x Victron Orion 12/24-8 DC-DC Converter (IP20)
Installation Notes
This converter must be installed in a dry, protected enclosure away from moisture, condensation and direct exposure to the elements. The non-isolated design requires careful attention to grounding: input and output share a common negative, which must be accounted for in the system wiring design. Connection to battery systems and vehicle or marine electrical circuits should be carried out by a qualified electrician or competent installer familiar with DC power systems. Ensure adequate ventilation around the unit to prevent heat build-up during continuous operation.
