xVictron Orion 24/12-30 Non-Isolated DC-DC Converter IP20
The Victron Orion 24/12-30 is a non-isolated DC-DC converter that steps down a 24V DC input to a regulated 12V DC output at up to 30A. It is designed for professional vehicle, marine and off-grid installations where a 24V system bus needs to supply 12V loads without a separate battery bank.
Key Features
- Non-isolated step-down (buck) converter: 24V input to 12V output at up to 30A continuous current.
- IP20 protection rating: suitable for installation in enclosed, dry equipment bays and control panels.
- Compact and lightweight at 0.7 kg, making it straightforward to mount in space-constrained installations.
- Fixed output voltage of 12V, providing a stable supply for 12V accessories, lighting, control circuits and ancillary loads.
- Non-isolated topology delivers high efficiency with minimal heat generation compared to linear regulators.
- Victron Orion range: a well-established product line with a broad install base across marine, vehicle and off-grid applications.
Product Overview
The Orion 24/12-30 uses a non-isolated buck converter topology to step down a 24V DC supply to a regulated 12V output. Non-isolated converters share a common ground between input and output, which is acceptable in the majority of vehicle and marine installations where the chassis or hull forms a shared negative. The 30A output rating gives a maximum output power of 360W, sufficient to run a substantial 12V load from a 24V system bus.
Because the converter is non-isolated, it is not suitable for applications where input and output circuits must be kept electrically separate. In those cases, Victron's isolated Orion-Tr range would be the appropriate choice. For standard 24V-to-12V step-down duties in a shared-ground system, the non-isolated design is the more efficient and cost-effective option.
The IP20 rating means the unit is protected against solid objects greater than 12mm but carries no water or dust ingress protection. It must be installed in a dry, enclosed location such as a battery compartment, equipment locker or control panel enclosure. It is not suitable for direct exposure to moisture, spray or condensation.
Specifications
- SKU: ORI241230022
- Input voltage: 24V DC (nominal)
- Output voltage: 12V DC
- Output current: 30A
- Maximum output power: 360W
- Topology: Non-isolated (buck)
- Protection rating: IP20
- Weight: 0.7 kg
- GTIN: 8719076069591
Applications
- Supplying 12V accessories and control circuits from a 24V vehicle or truck electrical system.
- Powering 12V loads aboard vessels with a 24V DC house bank.
- Off-grid cabins and installations with a 24V battery system requiring a 12V sub-circuit.
- Telecom and industrial enclosures where a 24V bus feeds 12V control or communications equipment.
- Motorhomes and coaches with a 24V chassis system needing a regulated 12V auxiliary supply.
What Is Included
- 1 x Victron Orion 24/12-30 non-isolated DC-DC converter
Installation Notes
This unit must be installed in a dry, enclosed location in line with its IP20 rating. Ensure input wiring is correctly fused close to the source battery or busbar. The non-isolated design requires a shared negative (common ground) between the 24V input and 12V output circuits. It is not suitable for applications requiring galvanic isolation. Installation should be carried out by a qualified 12/24V DC systems installer familiar with vehicle, marine or off-grid wiring practices. Verify that cable sizing is appropriate for the 30A output current and that adequate ventilation is provided around the unit to allow heat dissipation.
