Description
xPhoenix Inverter 48/800 230V VE.Direct UK
The Victron Phoenix Inverter 48/800 is a pure sine wave inverter designed for off-grid and backup power applications. It converts 48V DC battery power to 230V AC at 800VA continuous output, making it suitable for professional installations in boats, vehicles, remote cabins and off-grid systems. VE.Direct connectivity allows monitoring and configuration via Victron's GX devices or the VictronConnect app.
Key Features
- 800VA continuous output at 230V AC from a 48V DC battery bank.
- Pure sine wave output suitable for sensitive electronics and motor loads.
- VE.Direct port for direct communication with GX monitoring devices and the VictronConnect app via Bluetooth or USB interface.
- UK plug configuration included, ready for domestic 230V AC connections.
- Compact and lightweight design at 5.8 kg, suited to space-constrained installations.
- Built-in protections covering low battery voltage shutdown, over-temperature and short circuit.
- Wide input voltage range typical of the Phoenix range, accommodating varying battery states of charge.
Product Overview
The Phoenix 48/800 sits at the entry level of Victron's 48V inverter range. At 800VA, it is sized for loads such as lighting circuits, small appliances, power tools and communication equipment in off-grid or backup scenarios. The pure sine wave output means it is compatible with virtually any AC load, including inductive loads such as pumps and compressors that modified sine wave inverters cannot reliably drive.
VE.Direct is Victron's wired serial communication protocol. On this inverter it enables real-time monitoring of battery voltage, output power and device status through a GX device (such as a Cerbo GX) or directly via a VE.Direct to USB cable connected to a laptop or Raspberry Pi running Venus OS. The VictronConnect app can also connect wirelessly when used with a VE.Direct Bluetooth Smart dongle. This level of integration is particularly useful in managed off-grid systems where the inverter forms part of a wider Victron installation.
The 48V nominal input voltage is well suited to larger battery banks where higher voltage reduces cable losses and allows more efficient energy storage. This model is specified for the UK market with a 230V AC output and appropriate plug configuration.
Technical Specifications
| Parameter | Value |
| SKU | PIN481801400 |
| Nominal DC Input Voltage | 48V |
| Continuous Output Power | 800VA |
| AC Output Voltage | 230V AC |
| Output Waveform | Pure sine wave |
| Communication | VE.Direct |
| Market / Plug | UK |
| Weight | 5.8 kg |
| GTIN | 8719076056898 |
Applications
- Off-grid cabins and remote buildings requiring 230V AC from a 48V battery bank.
- Marine and narrowboat installations powering domestic AC loads from a 48V house bank.
- Vehicle conversions (motorhomes, expedition vehicles) needing a compact 230V inverter.
- Backup power for communications equipment, routers and small office loads.
- Part of a larger Victron off-grid system monitored via a GX device.
What Is Included
- Victron Phoenix Inverter 48/800 230V VE.Direct (UK) unit.
Installation Notes
Installation should be carried out by a qualified electrician or experienced system integrator. The inverter must be connected to a correctly fused 48V DC supply with appropriately rated cabling to handle the peak current draw. For any installation forming part of a grid-connected or grid-backup system, compliance with current UK wiring regulations (BS 7671) and relevant network operator requirements applies. Ensure adequate ventilation around the unit to prevent thermal shutdown. VE.Direct accessories such as a Bluetooth Smart dongle or USB interface cable are sold separately if remote monitoring is required.
