xVictron Smart IP43 Charger 36V/15A (1 Output) 120-240V
The Victron Smart IP43 Charger 36/15(1) is a single-output, 15-amp battery charger designed for 36V battery banks. It accepts a wide input voltage range of 120 to 240V AC, making it suitable for use across the UK, Europe and North America. It is aimed at professional installers, marine and vehicle applications, and off-grid systems where reliable, monitored charging is required.
Key Features
- 36V output at 15A with a single output channel for dedicated battery charging.
- Wide AC input range of 120 to 240V covers UK, EU and North American mains supplies without modification.
- IP43 rated enclosure provides protection against solid objects over 1mm and water spray at up to 60 degrees from vertical.
- Built-in Bluetooth via the VictronConnect app allows real-time monitoring and configuration from a smartphone or tablet without additional hardware.
- Adaptive multi-stage charging algorithm adjusts charge profile based on battery condition to extend battery service life.
- Compatible with lithium (LiFePO4), AGM, gel and flooded lead-acid battery chemistries via selectable charge profiles.
- Storage mode automatically reduces float voltage after 24 hours to minimise battery stress during long-term storage.
Product Overview
The Smart IP43 Charger connects directly to Victron's VictronConnect platform over Bluetooth. This removes the need for a separate interface device during commissioning or routine checks. Installers can read charge state, adjust battery type settings and review historical data directly from a phone. No dongle or additional hardware is required.
The IP43 rating is appropriate for sheltered indoor installations such as engine rooms, battery compartments and utility spaces where the charger will not be exposed to direct water ingress. It is not rated for outdoor or fully exposed environments. The 36V output voltage makes this charger suited to 36V traction, leisure and industrial battery banks where 12V or 24V chargers are not appropriate.
The adaptive charging algorithm monitors battery response during each charge cycle and adjusts the absorption time accordingly. A battery that charges quickly receives a shorter absorption phase, reducing heat and stress. A battery that has been deeply discharged receives a longer absorption phase to ensure full recovery. This behaviour is automatic and requires no manual adjustment after initial setup.
Specifications
- SKU: PSC361550095
- Output voltage: 36V
- Output current: 15A
- Number of outputs: 1
- AC input voltage: 120 to 240V
- IP rating: IP43
- Weight: 2.85kg
- GTIN: 8719076075431
Applications
- Charging 36V lead-acid or lithium battery banks in off-grid and backup power systems.
- Marine and narrowboat installations with 36V house battery configurations.
- Electric vehicle auxiliary charging for 36V traction battery systems.
- Industrial and commercial equipment with 36V battery supplies.
- Workshop or depot charging stations where mains voltage varies between 120V and 240V.
What Is Included
- Victron Smart IP43 Charger 36/15(1) unit
Installation Notes
This charger should be installed by a qualified electrician or competent person familiar with battery systems and mains AC wiring. Ensure the AC supply is correctly fused and that the battery bank voltage matches the 36V output before connecting. Select the correct battery chemistry profile via VictronConnect before first use. The IP43 rating is suitable for sheltered indoor locations only. Do not install in locations exposed to direct rain, spray wash-down or condensation without additional enclosure protection.
