xVictron Smart IP43 Charger 48V/13A (1 Output) 120-240V
The Victron Smart IP43 Charger 48/13 is a single-output mains battery charger designed for 48V battery banks. It accepts a wide input voltage range of 120 to 240V AC, making it suitable for use across the UK, Europe and North America. It is aimed at professional installers, off-grid system integrators and commercial operators who need a reliable, Bluetooth-enabled charger for 48V applications.
Key Features
- 48V output at 13A charge current, with a single output channel for direct battery connection.
- Wide AC input range of 120 to 240V, compatible with both UK/EU and North American mains supplies.
- Built-in Bluetooth connectivity allows configuration and monitoring via the VictronConnect app on iOS and Android.
- IP43 ingress protection rating: protected against solid objects over 1mm and against water spray up to 60 degrees from vertical.
- Adaptive charging algorithm with automatic battery type detection and a configurable absorption and float voltage.
- Storage mode reduces float voltage after 24 hours to minimise battery stress during long-term standby.
- Temperature-compensated charging when used with an optional battery temperature sensor.
Product Overview
The Smart IP43 range uses a multi-stage adaptive charging algorithm. After bulk charging, the charger enters absorption phase and monitors battery acceptance current. Once the current drops below a set threshold, it transitions to float. This approach reduces overcharging risk and extends battery service life compared to fixed-timer chargers. The 48V/13A output is suited to medium-capacity 48V battery banks where a controlled, monitored charge is required.
Bluetooth integration via VictronConnect gives installers direct access to charge settings, real-time status and historical data without additional hardware. Battery type presets cover AGM, gel, lithium (LiFePO4) and flooded lead-acid. Custom charge profiles can also be programmed for non-standard battery chemistries. The wide AC input range means the same unit can be used in UK and EU installations without modification.
The IP43 rating makes this charger suitable for installation in plant rooms, battery enclosures and light-industrial environments where some exposure to dust and moisture is possible, though it is not rated for outdoor or fully wet environments.
Technical Specifications
| Parameter | Value |
| SKU | PSC481350095 |
| Output Voltage | 48V |
| Output Current | 13A |
| Number of Outputs | 1 |
| AC Input Voltage Range | 120 to 240V AC |
| IP Rating | IP43 |
| Connectivity | Bluetooth (VictronConnect) |
| Weight | 2.85 kg |
| GTIN | 8719076070566 |
Applications
- Charging 48V lead-acid or LiFePO4 battery banks in off-grid solar systems.
- Standby and maintenance charging for 48V telecom and UPS battery installations.
- Shore power battery charging on narrowboats, yachts and other marine vessels with 48V systems.
- Light commercial and industrial backup power systems requiring a monitored 48V charge source.
- Installations requiring dual-voltage mains compatibility (120V and 240V AC).
What Is Included
- 1x Victron Smart IP43 Charger 48/13 (1 output)
Installation Notes
This charger should be installed by a qualified electrician. Ensure the AC supply is correctly fused and that the battery bank voltage matches the 48V output before connection. For LiFePO4 batteries, verify that the charge profile is correctly configured in VictronConnect before use. The IP43 rating does not permit direct outdoor exposure or installation in locations subject to water ingress. Mains cord requirements will vary by country; confirm the appropriate plug and cable standard for the installation site.
