Description
xVE.Direct Cable 0.9m (One Side Right Angle Connector)
This is a 0.9m VE.Direct cable with a right angle connector on one end and a straight connector on the other. It is used to connect Victron devices that communicate over the VE.Direct protocol, such as MPPT solar charge controllers, BMV battery monitors and Phoenix inverters, to compatible displays, interfaces or other VE.Direct-enabled equipment. The right angle connector is useful where space behind the device is limited or where cable routing requires a low-profile exit.
Key Features
- 0.9m cable length, suitable for short-run connections between adjacent devices or panels.
- One right angle VE.Direct connector allows flush mounting against walls, enclosures or tight cabinet installations.
- One straight VE.Direct connector on the opposite end for standard port connection.
- Compatible with all Victron Energy devices that use the VE.Direct interface, including MPPT charge controllers, BMV monitors and Phoenix inverters.
- Lightweight at 25g, adding negligible weight to any installation.
- SKU: ASS030531209 | GTIN: 8719076019664
Product Overview
VE.Direct is Victron's proprietary serial communication protocol used across a wide range of their products. The cable carries data between devices, enabling monitoring, configuration and integration with systems such as the Victron Color Control GX, GlobalLink 520 or a laptop running VictronConnect. This 0.9m variant is the shortest standard length available, making it appropriate where devices are mounted close together and cable management is a priority.
The right angle connector on one end reduces the clearance depth required behind the device. This is particularly useful in flush-mounted enclosures, narrow battery cabinets or installations where a straight cable exit would create strain or obstruct panel doors. The straight connector on the opposite end fits any standard VE.Direct port without modification.
Specifications
- Cable length: 0.9m
- Connector type: VE.Direct (one right angle, one straight)
- Weight: 0.025kg (25g)
- SKU: ASS030531209
- GTIN: 8719076019664
Applications
- Connecting a Victron MPPT charge controller to a Color Control GX or Cerbo GX in a compact enclosure.
- Linking a BMV battery monitor to a GX device or VE.Direct to USB interface for data logging.
- Connecting a Phoenix inverter to a monitoring or display device where cable routing space is restricted.
- Short-run data connections in off-grid battery cabinets, narrowboats, motorhomes and marine installations.
- Any installation where a straight cable exit would cause strain relief or clearance issues.
What Is Included
- 1x VE.Direct cable, 0.9m, with one right angle connector and one straight connector
Installation Notes
This cable carries data only and does not supply power to connected devices. Ensure both devices are powered down before connecting or disconnecting the cable. VE.Direct ports are not hot-swap rated on all devices, so check the relevant device documentation before connecting under live conditions. No specialist electrical qualification is required to connect this cable, but the wider system installation (inverters, charge controllers, battery connections) should be carried out by a qualified electrician or competent person.
