Description
xElios 15kW works as an on-grid solar inverter for three-phase networks. it optimizes energy yield in nearly every situation. It converts solar power to alternating current for direct self-consumption or export to the public grid. 320-478VAC
The inverter works with grid connection and supports export to the national grid or export limitation which is ideal for self-consumption.
If the power is not sold back to the grid, the current transformer (CT) needs to be installed to measure the energy consumption in the consumer unit of the property. Based on the amount of power (in watts), the inverter will feed as much energy as possible directly to the home appliances.
The inverter works with NET-Metering or Feed-in-Tariff, but if the export to the grid is required to be 0 watts, the current transformer (clamp meters) will adjust the power from the sun according to the energy consumption.
The fanless cooling system extends the life expectancy and eliminates the need for maintenance, the large aluminium heatsink provides sufficient natural convection cooling. The overall operation of the inverter is completely silent.
FEATURES
-
Wide input voltage range from 160V to 1000Vdc
-
IP65 protection, suitable for outdoor installation
-
Integrated DC solar switch
-
DSP Controller (Digital Signal Processing)
-
Peak efficiency at full load 98.3%
-
WI-FI Monitoring is integrated
-
Easy to install and user-friendly set up
-
Transformerless AC Output for higher efficiency and lightweight
-
Maximum PV Input 18000Watt
There are 3 independent MPPT controllers with a wide range from 200 to 1000VDC, an average of 20 panels in series may be connected to a single PV string.
The inverter is monitoring with WI-FI or using the Solar-Assistnt Orange PI controller
Dimensions: 500*428*200 mm
Weight:24.5kG
Specifications
x| MODEL | PH50- 15000TM | |
| Output (AC) | Rated AC output power | 15000W |
| Max.AC apparent power | 16500VA | |
| Max.output current | 23.8A | |
| Nominal AC Voltage | 230V \ 400V | |
| AC Voltage range | 184Vac-300Vac | |
| AC grid frequency range | 50±5Hz | |
| 60±5Hz | ||
| Power factor at Rated power | 1 | |
| Adjustable displacement power factor | 0.8leading. 0.8lagging | |
| THDi @ Full load%THDv <1% | < 3% | |
| AC grid connection type | 3W+N+PE | |
| Input Data | Max.DC power | 18000W |
| Max.DC voltage | 1000V | |
| Start voltage | 160V | |
| PV voltage range | 160V-1000V | |
| MPP voltage range | 200V-1000V | |
| Full load voltage range | 520V-850V | |
| Max.input current | 20A \ 10A | |
| Number of independent MPP trackers / strings per MPP tracker | \/2+1 | |
| DC connection | H4 \ MC4 | |
| Efficiency | Max.efficiency | 98.40% |
| Euro weighted efficiency | 98% | |
| MPPT efficiency | 99.50% | |
| Protection devices | DC reverse polarity protection, Output over current protection, Output overvoltage protection-varistor, DC reverse polarity protection, DC switch rating for each MPPT(opt.), Ground fault monitoring, Integrated all-pole sensitive leakage current monitoring unit | |
| GENERAL DATA FEATURES | Dimension(W/H/D)(mm) | 500*428*200 |
| Weight (kg) | 24 | |
| Operation temperature range | -25℃ - +60℃ with derating above 45℃ | |
| Noise emission(typical) | ≤35dB(A) | |
| Altitude | 3000m | |
| Self-consumption night | < 1W | |
| Topology | Transformerless | |
| Cooling concept | Natural | |
| Environmental protection Rating | Ip65 | |
| Relative humidity | 100% | |
| Features | AC connection | connector |
| Display | LED | |
| Interfaces:USB/WI-FI/GPRS/ RS485 | YES \ YES \ Opt \ YES | |
| Warranty | Standard 5 years \ 10 years (opt.) | |
| Certificates and approvals | CE \ IEC62109 | |
