xAdjustable Solar Panel Mounting Bracket for Trapezoidal Metal Roofs
A heavy-duty adjustable bracket for mounting solar panel rails on trapezoidal and sandwich panel metal roofs. Manufactured from SUS304 stainless steel with anti-corrosive treatment. Supplied as a complete set including screws, EPDM washer, rail mounting clamp, and bracket.
Key Features
- Adjustable design for a precise fit on trapezoidal metal (sandwich panel) roofs
- SUS304 stainless steel construction throughout
- Anti-corrosive surface treatment for long service life
- Two adjustable ends for a perfect fit across varying roof profile widths
- Supplied as a complete set: bracket, screws, EPDM washer, rail nut, and M8 bolt
- Mounts aluminium rails horizontally or vertically
Product Overview
This bracket is designed for the Easy-Click style of metal roof attachment, allowing aluminium mounting rails to be fixed horizontally or vertically to trapezoidal metal and sandwich panel roofing without the need for through-roof fixings. The two adjustable ends conform to the raised rib profile of the roof sheet, providing a tight and weatherproof contact point.
The EPDM washer beneath the fixing screw creates a weatherproof seal at the penetration point. The complete hardware set means no additional fixings are required for a standard installation.
To complete a full solar panel mounting kit, end clamps, middle clamps, and 1.2m aluminium rails are required in addition to these brackets.
Technical Specifications
| Parameter | Value |
| Material | SUS304 stainless steel |
| Roof Type | Trapezoidal metal roof, sandwich panel |
| Fixing Screw | SUS304 Phi 6.3 x 25mm |
| Rail Bolt | SUS304 M8 x 25mm with rail nut and washer |
| Seal | EPDM washer included |
| Rail orientation | Horizontal or vertical |
| SKU | ING-MRB-T04 |
| Sold as | Per complete set |
Applications
- Solar PV installations on trapezoidal metal sheet roofs
- Agricultural buildings, industrial units, and commercial premises with metal roofing
- Any roof installation requiring a non-penetrating rail attachment to a raised-rib metal profile
What Is Included
- 1x SUS304 stainless steel adjustable bracket
- 1x SUS304 Phi 6.3 x 25mm fixing screw
- 1x EPDM weatherproof washer
- 1x M8 x 25mm SUS304 bolt with rail nut and washer
Installation and Safety Notes
Metal roof solar panel mounting systems must be designed and installed by a qualified solar installer or roofing contractor. Verify roof load capacity before installation. Ensure all penetration points are correctly sealed to maintain roof waterproofing. End and middle clamps and aluminium rails are required separately to complete the mounting system.
