xVictron Energy ANL Fuse 500A/80V (Pack of 5)
The Victron Energy ANL fuse 500A/80V is a high-current DC protection fuse designed for use in battery systems, inverter installations and other high-amperage DC circuits. Sold in a pack of five, it is suited to installers and system integrators who need reliable overcurrent protection across multiple installations.
Key Features
- 500A continuous current rating for high-capacity DC circuits
- 80V DC voltage rating, compatible with 12V, 24V and 48V battery systems
- ANL format fuse, designed for use with standard ANL fuseholders
- Provides overcurrent and short-circuit protection for inverters, battery banks and DC distribution
- Pack of 5 fuses, suitable for trade, installer and multi-system use
- Victron Energy part number CIP143500020, GTIN 8719076061793
Product Overview
ANL fuses are a standard format for high-current DC protection in battery-based energy systems. The blade-style construction allows for straightforward installation into a compatible ANL fuseholder, providing a clear and serviceable point of overcurrent protection between the battery bank and the load or inverter.
At 500A, this fuse is appropriate for large inverter installations, high-capacity battery banks and DC busbars where fault currents could otherwise cause significant damage. The 80V rating covers the full range of common battery voltages used in off-grid, marine and vehicle installations, including 48V systems operating at elevated charge voltages. Always match the fuse rating to the cable and system design rather than simply the inverter's nominal current draw.
Specifications
- Current rating: 500A
- Voltage rating: 80V DC
- Fuse type: ANL
- Pack quantity: 5 fuses
- Weight: 0.1 kg (per pack)
- SKU: CIP143500020
- GTIN: 8719076061793
Applications
- Overcurrent protection on inverter DC input cables in off-grid and hybrid solar systems
- Battery bank protection in 12V, 24V and 48V installations
- DC distribution boards and busbars in marine and motorhome electrical systems
- Protection of high-current DC wiring in commercial vehicle and industrial battery systems
- Replacement fuses for existing ANL fuseholder installations
What Is Included
- 5 x Victron Energy ANL fuse 500A/80V
Installation Notes
ANL fuses must be installed in a compatible ANL fuseholder rated for the voltage and current of the circuit. Fuses should be positioned as close to the battery positive terminal as practicable to maximise protection of the wiring. Ensure the fuseholder connections are clean and torqued to the manufacturer's specification to prevent resistance heating at the contact points. High-current DC systems carry significant fault energy and installation should be carried out by a qualified electrician or accredited installer familiar with DC battery systems.
