Description
xVictron Argodiode 120-2AC Battery Isolator 2 Batteries 120A
The Victron Argodiode 120-2AC is a diode-based battery isolator designed to charge two separate battery banks simultaneously from a single alternator or charger, without allowing current to flow between them. It is suited to marine, vehicle and off-grid applications where battery bank separation is essential.
Key Features
- 120A continuous current rating supports high-demand charging from a single alternator source.
- Two output circuits allow simultaneous, isolated charging of two independent battery banks.
- Diode isolation prevents discharge from one battery bank to another, protecting starter and service batteries from cross-drain.
- 2AC designation indicates two Schottky diode pairs with a common anode input, minimising voltage drop compared to standard silicon diodes.
- Compact aluminium heatsink body dissipates heat effectively without requiring active cooling.
- Compatible with 12V and 24V systems, making it suitable for a wide range of vehicle and marine installations.
Product Overview
The Argodiode 120-2AC uses Schottky diodes rather than conventional silicon diodes. This matters in practice because Schottky diodes have a lower forward voltage drop, typically around 0.3V to 0.5V less than standard diodes. In charging applications, this reduced drop means battery banks receive a voltage closer to the alternator or charger output, which is particularly important when charging lead-acid or AGM batteries that require accurate voltage regulation.
The isolator accepts a single input from an alternator or DC charger and splits the output to two battery banks through separate diode paths. Because the diodes are unidirectional, neither battery can discharge into the other, and a fault or deep discharge on one bank does not affect the other. The aluminium body acts as the heatsink and should be mounted to a flat metal surface or bulkhead to ensure adequate thermal performance at sustained high currents.
Specifications
- SKU: ARG120201020R
- Maximum current: 120A
- Number of battery outputs: 2
- Diode type: Schottky (2AC configuration)
- Compatible system voltages: 12V and 24V
- Weight: 0.8 kg
- GTIN: 8719076019084
Applications
- Marine vessels requiring separation of starter and domestic battery banks charged from a single alternator.
- Motorhomes and campervans with separate engine start and leisure battery banks.
- Commercial vehicles with auxiliary battery systems for refrigeration, tail lifts or other loads.
- Off-grid installations where a single charger must maintain two isolated battery banks.
- 4x4 and overland vehicles with dual battery setups.
What Is Included
- 1 x Victron Argodiode 120-2AC battery isolator unit
Installation Notes
The Argodiode should be mounted on a thermally conductive metal surface to allow heat dissipation at full rated current. Ensure all cable connections are correctly rated for 120A and that appropriate fusing is fitted on the input and each output circuit. Installation in marine and vehicle electrical systems should be carried out by a qualified electrician or accredited installer familiar with the relevant wiring standards. The voltage drop across the diodes should be accounted for when setting the alternator or charger output voltage to ensure batteries receive the correct charge voltage.
