xBattery Monitor BMV-710H Smart
The Victron BMV-710H Smart is a high-precision battery monitor designed for systems operating at higher voltages, up to 400V DC. It is suited to professional installers and off-grid system designers working with high-voltage battery banks, including lithium and lead-acid configurations. The BMV-710H tracks state of charge, voltage, current and consumed amp-hours with accuracy that basic voltmeters cannot match.
Key Features
- Measures battery voltage up to 400V DC, making it compatible with high-voltage battery systems beyond the range of standard BMV monitors.
- Displays state of charge (%), voltage, current, power, consumed amp-hours (Ah) and time remaining.
- Built-in Bluetooth via the VictronConnect app for wireless configuration, monitoring and data logging on iOS and Android devices.
- Programmable relay output for alarms, load control or generator start signals based on configurable thresholds.
- 500A shunt included as standard; compatible with external shunts for higher current applications.
- Backlit display with intuitive navigation across all monitored parameters.
- Stores historical data including deepest discharge, average discharge, total Ah drawn and number of charge cycles.
Product Overview
The BMV-710H is the high-voltage variant of Victron's BMV-710 Smart monitor. Where the standard 710 is rated to 95V, the 710H extends this to 400V DC, which is essential for series-connected battery banks or high-voltage DC bus systems. This makes it appropriate for larger off-grid installations, industrial backup systems and certain EV or marine applications where battery strings operate well above 48V.
Accurate state of charge monitoring depends on precise current measurement over time. The BMV-710H uses a 500A shunt and a high-resolution current measurement circuit to calculate consumed amp-hours continuously. The Peukert exponent and charge efficiency factor are both configurable, allowing the monitor to be tuned to the actual behaviour of the battery chemistry in use, whether flooded lead-acid, AGM, gel or lithium.
Bluetooth connectivity is built in rather than added via a dongle. The VictronConnect app provides full access to settings, live data and historical logs without requiring a separate GX device. For installations integrated into a Victron system with a Cerbo GX or similar, the BMV-710H also communicates over VE.Direct.
Technical Specifications
| Parameter | Value |
| SKU | BAM030710100 |
| Battery voltage range | Up to 400V DC |
| Shunt included | 500A / 50mV |
| Communication | Bluetooth (built-in), VE.Direct |
| App compatibility | VictronConnect (iOS and Android) |
| Relay output | Programmable (alarm, load, generator start) |
| Weight | 0.74 kg |
| GTIN | 8719076049500 |
Applications
- High-voltage off-grid battery banks where series-connected cells exceed 48V or 96V.
- Industrial and commercial backup power systems with high-voltage DC bus configurations.
- Marine installations with elevated battery string voltages.
- Monitoring amp-hour consumption and state of charge in lithium battery systems requiring accurate Peukert compensation.
- Systems integrated with Victron GX devices via VE.Direct for centralised monitoring.
What Is Included
- BMV-710H Smart battery monitor unit with display
- 500A / 50mV shunt
- Connection cables and hardware
- VE.Direct cable (for GX device connection)
Installation Notes
The BMV-710H operates at voltages up to 400V DC. Installation at these voltage levels carries a significant risk of electric shock and arc flash. This monitor must be installed by a qualified electrician or experienced off-grid systems installer. The shunt must be placed on the negative battery terminal with all loads and chargers connected on the load side of the shunt. Ensure the system is fully de-energised before making any connections. For systems integrated into grid-connected installations, consult your DNO and ensure compliance with applicable UK wiring regulations.
