Description
xCurrent Transformer 400A:50mA for MultiPlus-II (10m) Wire-End
This current transformer is designed for use with the Victron MultiPlus-II inverter/charger, providing accurate AC current measurement via a 10-metre wire-end connection. It is intended for professional installers who need to monitor grid or generator current as part of a managed energy system.
Key Features
- 400A:50mA ratio provides accurate current sensing across a wide load range.
- 10-metre cable length gives flexibility in panel and enclosure placement without extension wiring.
- Wire-end termination for direct connection to compatible Victron monitoring inputs.
- Designed specifically for use with the Victron MultiPlus-II inverter/charger range.
- Compact and lightweight at 0.25 kg, suitable for installation in standard distribution boards and enclosures.
- Split-core or solid-core design allows installation around existing conductors without breaking the circuit.
Product Overview
Current transformers (CTs) are used to measure alternating current in a conductor by producing a proportional secondary current, in this case 50mA at full 400A primary load. This signal is fed to the MultiPlus-II's CT input, enabling the inverter to monitor grid import and export in real time. Accurate current measurement is essential for correct power assist, grid feed-in control and ESS (Energy Storage System) operation.
The 10-metre cable length is a practical advantage in installations where the metering point is some distance from the inverter or GX device. This avoids the need for field-spliced extensions, which can introduce signal errors. The wire-end format means the installer connects directly to the designated terminal on the MultiPlus-II without requiring an intermediate connector.
This CT is a required accessory for MultiPlus-II installations where grid current monitoring is needed, particularly in ESS configurations where the system must track net grid power to manage charge and discharge behaviour correctly.
Specifications
- SKU: CTR140050100
- Primary current rating: 400A
- Secondary output: 50mA
- Cable length: 10 metres
- Termination: Wire-end
- Weight: 0.25 kg
- GTIN: 8719076065746
Applications
- Grid current monitoring in Victron MultiPlus-II ESS installations.
- Power assist configurations where grid import must be measured and limited.
- Residential and light commercial solar-plus-storage systems using the MultiPlus-II.
- Installations where the metering point is up to 10 metres from the inverter location.
What Is Included
- 1 x Current Transformer 400A:50mA with 10-metre wire-end cable
Installation Notes
This current transformer must be installed by a qualified electrician familiar with Victron MultiPlus-II systems and ESS configuration. The CT must be clipped around the correct conductor (typically the grid live feed) and oriented in the correct direction as specified in the MultiPlus-II installation manual. Incorrect orientation will result in reversed current readings and improper system behaviour. For grid-connected ESS installations in the UK, the system must comply with G98 or G99 requirements as applicable. Do not install around bundled or multi-core cables containing more than one current-carrying conductor.
