Description
xVictron EasySolar-II 24/3000/70-32 MPPT 250/70 GX
The EasySolar-II GX is an all-in-one inverter charger for 24V off-grid and self-consumption systems. It combines a MultiPlus inverter charger, MPPT solar charge controller and GX monitoring device in a single wall-mounted unit. Designed for professional installers building residential or light commercial off-grid and backup power systems.
Key Features
- 3000VA inverter with 70A battery charger built in, rated for 24V battery banks
- MPPT 250/70 solar charge controller handles up to 250V open-circuit PV voltage and 70A charge current
- Integrated GX device provides onboard monitoring, VRM portal connectivity and DVCC support
- 32A AC input current limit for shore power or generator connection
- PowerAssist function allows the unit to supplement AC input with inverter power, preventing overload of a limited supply
- Single enclosure design reduces wiring complexity and installation time compared to separate components
- Compatible with Victron VE.Bus, VE.Direct and VE.Can ecosystem for full system integration
- SKU: PMP242307010 | GTIN: 8719076049265 | Weight: 25.4 kg
Product Overview
The EasySolar-II GX integrates three core system components into one enclosure: the MultiPlus inverter charger, an MPPT solar charge controller and a GX monitoring controller. For a 24V system, the 3000VA continuous output covers most residential loads, and the 70A MPPT handles PV arrays up to 250V Voc. The GX device runs Venus OS, giving installers access to the VRM online portal, local touchscreen display support and full DVCC (Distributed Voltage and Current Control) for managed battery systems.
The 70A battery charger uses an adaptive four-stage charging algorithm and supports a wide range of battery chemistries including lead-acid, AGM, gel and lithium. The 32A AC input accepts shore power or a generator, and PowerAssist prevents the AC source from being overloaded by supplementing it with inverter output when loads spike. This makes the unit well suited to sites with a limited generator or restricted grid connection.
Because the MPPT, inverter and GX controller share a single enclosure, there is no need for separate VE.Direct or VE.Bus cabling between those components. This simplifies commissioning and reduces potential points of failure. The unit still connects to external Victron devices via VE.Bus, VE.Direct and VE.Can ports, so it integrates fully into larger Victron systems.
Technical Specifications
| Parameter | Value |
| SKU | PMP242307010 |
| Inverter Output | 3000VA / 2400W |
| Battery Voltage | 24V |
| Battery Charger Current | 70A |
| AC Input Current Limit | 32A |
| MPPT Model | SmartSolar MPPT 250/70 |
| Max PV Open-Circuit Voltage | 250V |
| Max MPPT Charge Current | 70A |
| Integrated GX Device | Yes (Venus OS) |
| Weight | 25.4 kg |
| GTIN | 8719076049265 |
Applications
- Off-grid residential systems with solar PV and battery storage
- Backup power installations where generator or limited grid supply is the AC input
- Marine and vehicle applications requiring a 24V all-in-one inverter charger with solar
- Self-consumption and home storage systems on a 24V battery bank
- Remote site power where a single compact unit is preferred over multiple components
What Is Included
- EasySolar-II 24/3000/70-32 MPPT 250/70 GX unit
Installation Notes
Installation must be carried out by a qualified electrician or accredited installer. The unit connects to 24V battery banks and accepts AC input from shore power or a generator. For any grid-connected application in the UK, ensure compliance with G98 or G99 requirements as applicable. Battery connections at this current rating involve significant fault energy; appropriate fusing and cable sizing is essential. Commissioning via the VRM portal and Venus OS is recommended to verify system configuration before handover.
