Description
xVictron Inverter 12V/1600W 230V VE.Direct SCHUKO
The Victron Inverter 12/1600 is a pure sine wave inverter designed to convert 12V DC battery power to 230V AC at 1600W continuous output. It is aimed at off-grid installations, vehicles, boats and backup power applications where a reliable AC supply is needed from a 12V battery bank. The SCHUKO output socket makes it straightforward to connect standard European and UK-compatible appliances directly.
Key Features
- 1600W continuous AC output from a 12V DC input, with a pure sine wave output suitable for sensitive electronics and motor loads.
- VE.Direct communication port enables monitoring and configuration via Victron's GX devices, MPPT Solar Chargers and the VictronConnect app over Bluetooth (with optional dongle).
- SCHUKO output socket for direct connection of standard 230V appliances without additional adapters in most European installations.
- Built-in protections include over-temperature, over-load, low battery voltage shutdown and short-circuit protection.
- Compact and relatively lightweight at 8.86 kg, making it practical for mobile and space-constrained installations.
- Low idle power consumption reduces unnecessary battery drain when running at light loads.
Product Overview
The 12/1600 sits in Victron's VE.Direct inverter range, which is designed for straightforward integration into Victron-based systems. The VE.Direct port allows the inverter to communicate with compatible Victron equipment, including Cerbo GX and Venus GX units, giving installers visibility of inverter status and load data within a broader energy management setup. This is particularly useful in off-grid cabins, campervans and marine installations where system monitoring matters.
At 1600W continuous, this inverter is suited to moderate loads: lighting circuits, small power tools, laptops, televisions, refrigerators and similar appliances. The pure sine wave output means it will handle inductive loads such as motors and compressors without the compatibility issues that modified sine wave inverters can cause. Battery protection thresholds are set to prevent deep discharge, which is important for battery longevity in off-grid and mobile applications.
The SCHUKO socket format is standard across continental Europe and is also widely used in the UK with appropriate adapters. Installers should verify the output socket type meets the requirements of the specific installation before commissioning.
Technical Specifications
| Parameter | Value |
| SKU | PIN122161200 |
| DC Input Voltage | 12V |
| Continuous AC Output Power | 1600W |
| AC Output Voltage | 230V |
| Output Waveform | Pure sine wave |
| Output Socket | SCHUKO |
| Communication | VE.Direct |
| Weight | 8.86 kg |
| GTIN | 8719076066347 |
Applications
- Off-grid cabins and remote buildings powered by a 12V battery bank with solar charging.
- Campervan and motorhome conversions requiring a 230V AC supply from the vehicle's leisure battery.
- Marine and narrowboat installations where 230V appliances need to run from a 12V DC system.
- Backup power for small offices or workshops during grid outages.
- Mobile work vehicles needing AC power for tools or equipment on site.
What Is Included
- Victron Inverter 12/1600 230V VE.Direct SCHUKO unit
Installation Notes
This inverter should be installed by a qualified electrician familiar with DC and AC electrical systems. DC cable sizing between the battery and inverter is critical at 12V: high currents are drawn at full load and undersized cabling will cause voltage drop and heat. Fuse or circuit-breaker protection must be fitted on the DC supply as close to the battery as practicable. The inverter is not grid-tied and does not require G98 or G99 notification. For installations in vehicles or vessels, ensure adequate ventilation around the unit to allow for thermal management. VE.Direct connectivity requires a compatible Victron GX device or VictronConnect Bluetooth dongle, neither of which is included.
