xVictron Inverter 12/3000 230V VE.Bus
The Victron Inverter 12/3000 230V is a pure sine wave inverter designed for professional off-grid and mobile power applications. It converts 12V DC battery power to 230V AC at 3000VA continuous output, making it suited to demanding loads in marine, vehicle, and off-grid installations. VE.Bus connectivity allows integration with Victron system components for monitoring and control.
Key Features
- 3000VA continuous output at 230V AC from a 12V DC battery bank.
- Pure sine wave output suitable for sensitive electronics, motors, and compressors.
- VE.Bus interface enables multi-unit parallel and three-phase configuration, as well as integration with Victron GX devices and system monitoring.
- High surge capacity to handle inrush currents from motors and pumps at start-up.
- Comprehensive protection including over-temperature, over-load, short circuit, and low battery voltage shutdown.
- Compact and robust aluminium housing with a weight of 18.8 kg, suitable for permanent installation in confined spaces.
- Compatible with Victron VE.Bus BMS and MultiPlus/Quattro systems for expandable off-grid architectures.
Product Overview
The 12/3000 sits in Victron's inverter-only range, meaning it converts DC to AC but does not include a battery charger. This makes it the correct choice where charging is handled separately, such as in systems with an existing MPPT solar charger and a dedicated AC charger, or where weight and cost savings matter. The VE.Bus communication port is what distinguishes this unit from Victron's basic inverter range: it allows the inverter to be configured, monitored, and controlled via VEConfigure software and Victron GX devices such as the Cerbo GX.
VE.Bus also enables parallel operation, where two or more identical units are connected to increase total output capacity, and split-phase or three-phase configurations for larger installations. This scalability is particularly relevant for off-grid commercial sites, large boats, and vehicles where load requirements may grow or vary. The inverter communicates battery state and load data back to the GX device, giving full system visibility through the VRM portal.
At 12V input, this inverter requires a well-sized battery bank to sustain 3000VA loads without excessive voltage drop. At full output, draw from the battery bank will be substantial, so cable sizing and battery capacity must be calculated carefully. Victron publishes detailed wiring guidelines, and installation should be carried out by a qualified electrician or accredited installer.
Technical Specifications
| Parameter | Value |
| SKU | PIN123020000 |
| DC Input Voltage | 12V |
| Continuous Output Power | 3000VA |
| AC Output Voltage | 230V AC |
| Output Waveform | Pure sine wave |
| Communication Interface | VE.Bus |
| Weight | 18.8 kg |
| GTIN | 8719076023579 |
Applications
- Off-grid cabins and remote buildings where mains power is unavailable.
- Marine vessels requiring reliable 230V AC from a 12V battery bank.
- Large campervans, coaches, and specialist vehicles with high AC load requirements.
- Backup power systems where a separate charger is already installed.
- Scalable off-grid systems using VE.Bus parallel or three-phase configurations.
- Integration into Victron GX monitoring systems for full remote visibility via VRM.
What Is Included
- Victron Inverter 12/3000 230V VE.Bus unit
Installation Notes
This inverter operates at high DC currents from a 12V battery bank. Correct DC cable sizing, fusing, and terminal torque are critical to safe operation. Installation must be carried out by a qualified electrician. For off-grid systems connected to any AC distribution board, compliance with BS 7671 wiring regulations is required. VE.Bus configuration should be performed using Victron's VEConfigure software by a competent installer familiar with the Victron ecosystem. This product is not grid-tied and does not require G98 or G99 notification.
