Description
xVictron Inverter 24/800 230V VE.Direct SCHUKO
The Victron Inverter 24/800 is a pure sine wave inverter designed to convert 24V DC battery power to 230V AC at up to 800VA continuous output. It is aimed at off-grid installations, marine and vehicle applications, and backup power setups where a compact, reliable DC-to-AC inverter is required. The SCHUKO output socket makes it straightforward to connect standard European appliances directly.
Key Features
- 800VA continuous output at 230V AC from a 24V DC battery bank.
- Pure sine wave output suitable for sensitive electronics, motors and compressors.
- VE.Direct communication port for monitoring and integration with Victron GX devices and the VictronConnect app.
- SCHUKO output socket for direct connection of standard European plugs without additional adapters.
- Compact and lightweight design at 5.8 kg, suited to space-constrained installations.
- Built-in protections including low battery voltage shutdown, over-temperature and overload protection.
Product Overview
The 24/800 operates from a 24V nominal battery system, which is a common voltage for off-grid cabins, narrowboats, campervans and small backup power installations. At 800VA continuous, it can handle a practical range of loads including lighting, small power tools, laptops, televisions and other household appliances within its power rating. The pure sine wave output means it is not restricted to simple resistive loads and will run inductive loads such as motors and compressors without issue.
The VE.Direct port is a key practical feature for professional installations. It allows the inverter to communicate with Victron's GX range of system monitors (such as the Cerbo GX) and can be configured and monitored using the VictronConnect app over a VE.Direct to USB or Bluetooth dongle. This makes it straightforward to integrate into a wider Victron Energy management system, log performance data, and set operational parameters without needing additional hardware beyond the communication cable.
The SCHUKO socket is a practical choice for European and UK installations where standard continental plugs are in use. The inverter includes automatic protections that shut it down safely under low battery voltage, overload or over-temperature conditions, protecting both the inverter and the connected load.
Technical Specifications
| Parameter | Value |
| SKU | PIN241801200 |
| Nominal DC Input Voltage | 24V |
| Continuous Output Power | 800VA |
| AC Output Voltage | 230V AC |
| Output Waveform | Pure sine wave |
| Communication | VE.Direct |
| Output Socket | SCHUKO |
| Weight | 5.8 kg |
| GTIN | 8719076056058 |
Applications
- Off-grid cabins and remote buildings running from a 24V battery bank.
- Narrowboat and canal boat 230V AC supply from a 24V domestic battery system.
- Campervan and motorhome AC power for appliances and electronics.
- Small backup power systems for critical loads during grid outages.
- Telecoms and industrial enclosures requiring a monitored 230V AC supply from DC battery.
What Is Included
- Victron Inverter 24/800 230V VE.Direct SCHUKO unit.
Installation Notes
This inverter should be installed by a qualified electrician or experienced system integrator. DC connections to a 24V battery bank must be correctly fused and cabled to the appropriate cross-section for the current involved. The unit is not grid-tied and does not require G98 or G99 compliance, but any fixed AC wiring connected to its output must comply with BS 7671 wiring regulations. For marine installations, follow the relevant IEC or RYA guidance for onboard electrical systems. VE.Direct communication cables are sold separately.
