xVictron Lynx Smart BMS 1000 (M10)
The Lynx Smart BMS 1000 is a battery management system designed for use with Victron Lithium Smart batteries in 12V, 24V and 48V systems. It integrates directly into the Lynx DC distribution bus, providing centralised cell protection, system control and real-time monitoring for professional off-grid, marine and vehicle installations.
Key Features
- Rated for up to 1000A continuous DC current, suitable for high-demand systems with multiple battery banks.
- M10 bolt connections provide a secure, low-resistance interface with the Lynx busbar system.
- Integrates with VE.Can network for communication with Victron inverter/chargers, MPPT controllers and the GX device ecosystem.
- Controls pre-charge, charge disconnect and load disconnect functions to protect lithium cells from over-voltage, under-voltage and over-temperature conditions.
- Supports Victron Lithium Smart Battery series with automatic cell balancing data visible via VictronConnect.
- Built-in alarm relay output for external signalling to third-party equipment or generator start/stop circuits.
- Compatible with the Lynx Distributor and Lynx Power In modules for a modular, expandable DC distribution architecture.
Product Overview
The Lynx Smart BMS 1000 sits at the heart of a Victron lithium battery system, acting as the primary protection and communication hub between the battery bank and the rest of the installation. Unlike standalone BMS units, it is designed to slot directly into the Lynx busbar assembly, keeping DC wiring compact and well-organised at high current ratings.
Communication over VE.Can means the BMS can coordinate with MultiPlus and Quattro inverter/chargers, SmartSolar MPPT controllers and Cerbo GX or Venus GX devices. This allows the system to respond automatically to battery state: reducing charge current before a disconnect event, or shedding non-critical loads before a low-voltage cutoff. These coordinated responses reduce stress on the battery and avoid hard disconnects under load wherever possible.
The M10 designation refers to the bolt size used on the busbar connections. This is relevant when specifying cable lugs and torque settings during installation. The unit weighs 2.5 kg and is designed for fixed installation in a protected enclosure or switchboard.
Technical Specifications
| Specification | Detail |
| SKU | LYN034170210 |
| Continuous Current Rating | 1000A |
| Connection Type | M10 bolted busbar |
| Communication Interface | VE.Can |
| Compatible Battery Chemistry | Victron Lithium Smart (LiFePO4) |
| Weight | 2.5 kg |
| GTIN | 8719076057604 |
Applications
- Large off-grid solar installations using Victron Lithium Smart batteries with MultiPlus or Quattro inverter/chargers.
- Marine vessels requiring high-current DC distribution with integrated lithium battery protection.
- Heavy vehicle and coach conversions with 12V, 24V or 48V lithium battery systems.
- Commercial and industrial backup power systems built on the Victron Lynx modular busbar platform.
- Expandable battery installations where multiple Lynx modules are combined for high-capacity DC distribution.
What Is Included
- 1x Lynx Smart BMS 1000 (M10) unit
Installation Notes
The Lynx Smart BMS 1000 must be installed by a qualified electrician or accredited installer with experience in high-current DC lithium battery systems. Connections to Victron Lithium Smart batteries require correct VE.Can cabling and termination. M10 cable lugs must be used on all busbar connections and torqued to the manufacturer's specification. This unit is not suitable for lead-acid battery chemistries. For off-grid solar installations in the UK, an MCS-accredited installer is recommended.
