Description
xVictron Energy MEGA-Fuse 175A/80V (Pack of 5)
The Victron Energy MEGA-fuse 175A/80V is a high-current DC fuse designed to protect battery cables and electrical circuits in 12V, 24V and 48V systems. Supplied in a pack of five, it is suited to professional installers working on off-grid, marine, vehicle and battery storage installations where reliable overcurrent protection is required.
Key Features
- 175A continuous current rating provides overcurrent protection for heavy-gauge DC battery cables.
- 80V DC voltage rating makes it compatible with 12V, 24V and 48V battery systems.
- MEGA-fuse format is a widely used standard in automotive and marine DC protection applications.
- Pack of 5 fuses, suitable for stocking or multi-installation projects.
- Victron Energy part number CIP138175020, compatible with standard MEGA fuseholders.
- Compact and lightweight at 45g per pack, with minimal installation footprint.
Product Overview
MEGA-fuses are a bolt-down DC fuse format commonly used to protect main battery cables in inverter, charger and battery management installations. The 175A rating sits between typical 150A and 200A options, making it appropriate where cable sizing or equipment ratings call for a tighter protection threshold. The 80V DC rating covers all standard lead-acid and lithium battery voltages up to 48V nominal with adequate margin.
These fuses are designed for use with MEGA fuseholders, which accept the standard MEGA blade body and secure the fuse via bolt terminals. Correct fuse selection depends on cable cross-section, ambient temperature and the continuous current draw of the connected equipment. Always select a fuse rating that protects the cable, not just the load.
Specifications
- SKU: CIP138175020
- Current rating: 175A
- Voltage rating: 80V DC
- Pack quantity: 5 fuses
- Weight: 0.045 kg (per pack)
- GTIN: 8719076061694
Applications
- Main battery cable protection in off-grid solar installations with Victron inverters or inverter/chargers.
- DC circuit protection in marine electrical systems.
- Vehicle and motorhome leisure battery installations.
- Battery bank protection in 12V, 24V and 48V energy storage systems.
- Replacement fusing for existing MEGA fuseholder installations.
What Is Included
- 5 x Victron Energy MEGA-fuse 175A/80V
Installation Notes
MEGA-fuses must be installed in a compatible MEGA fuseholder rated for the application voltage and current. Fuses should be fitted as close to the battery positive terminal as practicable to provide maximum cable protection. DC electrical work on battery systems, particularly those above 48V or with high short-circuit current capacity, should be carried out by a qualified electrician or accredited installer. Verify that the fuse rating is appropriate for the cable cross-section in use before installation.
