xVictron MultiPlus Compact 12/1200/50-16 230V VE.Bus Inverter Charger
The Victron MultiPlus Compact 12/1200/50-16 is a combined inverter and battery charger in a single unit, designed for 12V DC systems with a 230V AC output. It is suited to marine, vehicle, off-grid and backup power installations where space is limited and reliable AC power is required from a battery bank.
Key Features
- Combined inverter and charger in one compact unit, reducing wiring complexity and installation space.
- 1200VA continuous inverter output at 230V AC from a 12V DC battery bank.
- 50A battery charger with adaptive charging algorithm to suit a range of battery chemistries.
- 16A AC transfer switch for connecting a shore power or generator input, with automatic changeover.
- VE.Bus communication interface for system integration, remote monitoring and configuration via Victron GX devices.
- PowerAssist function allows the unit to supplement shore or generator power when load demand exceeds the AC input limit.
- Configurable AC input current limit to protect generators or limited shore power supplies from overload.
Product Overview
The MultiPlus Compact operates as a full-featured inverter charger in a smaller enclosure than the standard MultiPlus range. When AC input is available (shore power or generator), the unit passes power through to connected loads and simultaneously charges the battery bank at up to 50A. When AC input is lost or disconnected, the transfer switch activates and the inverter takes over within milliseconds, providing uninterrupted power to critical loads.
The PowerAssist feature is particularly useful in installations where the available AC input is limited, such as a small generator or a marina shore power pedestal with a low amperage limit. The unit draws the balance of the required current from the battery bank, allowing loads to run that would otherwise trip the supply. This avoids the need to upsize the generator or shore connection solely to handle peak loads.
VE.Bus connectivity means the MultiPlus Compact can be integrated into a wider Victron system. It can be monitored and configured remotely using a Victron GX device (such as a Cerbo GX), and settings including charge current, AC input limit and battery type can be adjusted using VE.Configure software. This makes it a practical choice for professional installers building managed off-grid or hybrid systems.
Technical Specifications
| Parameter | Value |
| SKU | CMP122120000 |
| Battery Voltage | 12V DC |
| Inverter Output | 1200VA / 230V AC |
| Charger Output | 50A |
| AC Transfer Switch | 16A |
| AC Output Voltage | 230V |
| Communication | VE.Bus |
| Weight | 11.4 kg |
| GTIN | 8719076065074 |
Applications
- Marine vessels requiring reliable 230V AC power from a 12V battery bank with shore power charging.
- Motorhomes and large campervans where space is limited but a full inverter charger is required.
- Off-grid cabins and small buildings with a 12V battery system and occasional generator input.
- Backup power systems for critical loads where automatic transfer from mains to battery is needed.
- Mobile or vehicle-based installations requiring both AC output and battery charging from a single unit.
What Is Included
- Victron MultiPlus Compact 12/1200/50-16 230V VE.Bus inverter charger unit
Installation Notes
Installation should be carried out by a qualified electrician or accredited installer familiar with DC battery systems and 230V AC wiring. The unit must be connected to a suitably rated 12V battery bank with appropriate DC fusing and cabling. For any grid-connected or mains-tied application, compliance with local wiring regulations and network operator requirements applies. VE.Configure software (available from Victron) is required for full configuration of charge parameters, AC input limits and battery type settings. Ensure adequate ventilation around the unit during operation.
