xVictron MultiPlus Compact 24/1600/40-16 230V VE.Bus Inverter Charger
The Victron MultiPlus Compact 24/1600/40-16 is a combined inverter and battery charger in a single unit, designed for 24V battery systems with a 1600VA inverter output and a 40A charger. It is well suited to off-grid installations, marine and vehicle applications, and backup power systems where space and weight are a consideration.
Key Features
- 1600VA continuous inverter output at 230V AC, with a 3000W peak surge capacity to handle motor start loads.
- 40A three-stage battery charger (bulk, absorption, float) with adaptive charge algorithm for optimised battery life.
- 16A AC transfer switch allows connection to shore power or a generator, with near-instant switchover to protect sensitive loads.
- VE.Bus communication interface enables system integration, remote monitoring and configuration via Victron GX devices and VEConfigure software.
- PowerControl function limits the total AC current draw, preventing overload of a generator or shore power supply.
- PowerAssist function supplements shore or generator power with battery power during peak demand, allowing a smaller AC source to be used.
- Compact form factor at 11.4 kg, making it practical for installations with limited space.
Product Overview
The MultiPlus Compact combines a true sine wave inverter with a multi-stage battery charger in one housing. When AC input is available (shore power or generator), the unit charges the battery bank and passes power through to connected loads. When AC input is lost or disconnected, it switches to inverter mode automatically. The transfer time is fast enough for most computers and sensitive electronics to remain operational without interruption.
The VE.Bus interface is a key practical feature for professional installations. It allows multiple MultiPlus units to be configured in parallel for increased capacity, or in split-phase and three-phase configurations. It also enables full integration with Victron's GX monitoring devices (such as the Cerbo GX), giving installers and end users remote visibility of system status, battery state of charge, and AC input/output data.
PowerControl and PowerAssist are particularly useful in installations where the available AC supply is limited. PowerControl caps the charger current to prevent tripping the shore supply breaker. PowerAssist goes further by drawing on the battery to supplement the AC source during brief high-demand periods, effectively allowing a 16A shore connection to support loads that would otherwise exceed that limit.
Technical Specifications
| Parameter | Value |
| SKU | CMP242160000 |
| Battery Voltage | 24V DC |
| Inverter Output Power | 1600VA |
| Charger Output Current | 40A |
| AC Transfer Switch | 16A |
| AC Output Voltage | 230V AC |
| Communication Interface | VE.Bus |
| Weight | 11.4 kg |
| GTIN | 8719076065104 |
Applications
- Off-grid cabins and remote buildings with 24V battery banks requiring AC power and battery charging from a generator.
- Marine installations where shore power charging and inverter backup are needed in a compact, lightweight unit.
- Vehicle conversions (motorhomes, expedition vehicles) requiring 230V AC output from a 24V house battery system.
- Backup power systems for critical loads such as communications equipment, medical devices or security systems.
- Small off-grid solar systems where the MultiPlus is paired with a solar charge controller and GX monitoring device.
What Is Included
- 1x Victron MultiPlus Compact 24/1600/40-16 230V VE.Bus inverter charger unit
Installation Notes
Installation should be carried out by a qualified electrician or accredited installer familiar with DC battery systems and 230V AC wiring. The unit must be connected to a correctly fused and rated 24V battery bank. Where the MultiPlus is integrated into a solar or backup system with grid connection, all relevant UK wiring regulations and any applicable G98 or G99 requirements must be observed. VEConfigure software is required for advanced configuration and is available from Victron Energy. For parallel or three-phase configurations, additional setup via VE.Bus is required and should only be undertaken by installers with experience of Victron system design.
