xVictron MultiPlus-II 24/3000/70-32 230V GX Inverter Charger
The MultiPlus-II 24/3000/70-32 GX is a combined inverter, battery charger and transfer switch with an integrated GX controller, built for 24V battery systems. It is aimed at off-grid installations, backup power systems and self-consumption setups where monitoring and control need to be built into a single unit.
Key Features
- 3000VA continuous inverter output at 230V AC from a 24V DC battery bank
- 70A battery charger with adaptive charge algorithm for accurate, efficient charging
- 32A AC input current limit, adjustable via the GX interface or external control
- Integrated GX controller provides onboard monitoring, VRM portal connectivity and system control without a separate Cerbo GX or CCGX
- PowerControl and PowerAssist functions prevent overloading a limited AC source such as a generator or shore power connection
- Transfer switch with a typical switchover time of 20ms, fast enough to keep most loads running without interruption
- Supports ESS (Energy Storage System) configuration for grid-tied self-consumption and backup applications
- Compatible with Victron VE.Bus for parallel and three-phase system expansion
- Weight: 20kg
Product Overview
The MultiPlus-II GX combines what would otherwise be three separate devices: an inverter, a charger and a system monitor. The integrated GX controller handles communication between connected Victron components, logs data to the VRM online portal and allows remote monitoring and configuration. This reduces wiring complexity and cabinet space compared to pairing a standard MultiPlus-II with a standalone Cerbo GX.
The 70A charger uses a four-stage adaptive algorithm and supports multiple battery chemistries including lead-acid and lithium. The charge current and absorption voltage can be configured to match the battery bank in use. PowerAssist allows the unit to supplement a limited AC source with battery power, so a small generator can support loads that would otherwise exceed its rated output.
For grid-connected ESS applications in the UK, the MultiPlus-II GX must be configured and commissioned in accordance with G98 or G99 requirements depending on export capacity. This configuration must be carried out by a qualified installer using the Victron ESS assistant and appropriate grid code settings.
Technical Specifications
| Parameter | Value |
| SKU | PMP242306000 |
| Battery Voltage | 24V DC |
| Continuous Output Power | 3000VA / 2400W |
| AC Output Voltage | 230V AC |
| Charger Output Current | 70A |
| AC Input Current Limit | 32A |
| AC Input Voltage | 230V AC |
| Transfer Switch Time | Typically 20ms |
| GX Controller | Integrated |
| Weight | 20kg |
| GTIN | 8719076051695 |
Applications
- Off-grid cabins, lodges and remote buildings requiring a self-contained power system
- Marine and vehicle installations on 24V battery systems needing 230V AC output
- Backup power for critical loads where fast transfer from grid to battery is required
- Grid-tied ESS installations with battery storage for self-consumption and export control
- Generator-assisted systems where PowerAssist is needed to extend generator capacity
What Is Included
- 1x Victron MultiPlus-II 24/3000/70-32 230V GX inverter charger
Installation Notes
Installation must be carried out by a qualified electrician or accredited installer. The unit operates at 24V DC with high current battery connections and 230V AC mains. For grid-connected ESS use in the UK, G98 or G99 compliance is required and the appropriate grid code assistant must be configured before connection to the grid. Battery chemistry and capacity settings must be verified before commissioning. Do not connect to a battery bank without confirming voltage compatibility.
