Description
xPhoenix Charger 24/16 (2+1) 120-240V
The Victron Phoenix Charger 24/16 is a three-output battery charger designed for 24V battery banks. It delivers up to 16A on the primary output and provides two additional outputs for secondary batteries, making it well suited to marine, vehicle and off-grid installations where multiple battery banks need charging from a single unit.
Key Features
- 24V charger with 16A primary output and two additional outputs in a 2+1 configuration.
- Wide input voltage range of 120-240V AC, compatible with both North American and European shore power or generator supplies.
- Adaptive four-stage charging algorithm: bulk, absorption, float and storage, with automatic battery type detection.
- Temperature-compensated charging adjusts output voltage based on battery temperature to prevent overcharging.
- Compact and lightweight at 3.6kg, suitable for installation in confined spaces on boats, vehicles and off-grid cabins.
- Protection against reverse polarity, over-temperature and short circuit on the output.
- Compatible with Victron VE.Direct interface for monitoring and configuration via VictronConnect.
Product Overview
The Phoenix Charger range uses an adaptive charging algorithm that monitors battery behaviour during the absorption phase and adjusts charge time accordingly. This means a deeply discharged battery receives a full charge cycle, while a battery that is only partially discharged moves to float sooner, reducing unnecessary heat and stress on the cells. The 2+1 output configuration allows the main 24V service bank to be charged at full current while the two secondary outputs maintain starter or auxiliary batteries at a lower rate.
The 120-240V AC input makes this charger practical for installations that move between different power sources, such as a vessel that connects to shore power in both the UK and the United States, or a vehicle that charges from a generator with variable output voltage. The wide input range handles these scenarios without manual switching or additional transformers.
VE.Direct connectivity allows the charger to be monitored and configured using the VictronConnect app over Bluetooth (with a VE.Direct Bluetooth Smart dongle) or via USB. Charge parameters, battery type presets and absorption voltage can all be adjusted to match the specific battery chemistry in use.
Specifications
- SKU: PCH024016001
- Output voltage: 24V
- Output current: 16A (primary output)
- Output configuration: 2+1 (two secondary outputs)
- Input voltage: 120-240V AC
- Weight: 3.6kg
- GTIN: 8719076023272
Applications
- Marine installations with separate service and starter battery banks.
- Motorhomes and campervans with a main leisure bank and an engine start battery.
- Off-grid cabins and remote power systems charged from a generator.
- Vehicles operating across different regional power standards requiring a wide-input charger.
- Backup power systems where multiple battery banks must be maintained simultaneously.
What Is Included
- Victron Phoenix Charger 24/16 (2+1) 120-240V unit
Installation Notes
Installation should be carried out by a qualified electrician or experienced marine/vehicle electrician familiar with DC battery systems. Ensure the AC supply is correctly fused and that all DC output connections are appropriately rated for the current draw. The charger must be mounted in a ventilated location away from flammable materials. For installations on vessels, comply with applicable marine wiring standards. This charger is not grid-tied and does not require G98 or G99 notification.
