xPhoenix Inverter 12/250 230V VE.Direct SCHUKO
The Victron Phoenix Inverter 12/250 is a compact 12V DC to 230V AC pure sine wave inverter with a SCHUKO output socket and VE.Direct communication port. It is designed for small off-grid, mobile and backup power applications where a reliable 230V AC supply is needed from a 12V battery bank.
Key Features
- 250VA continuous output power from a 12V DC input, with a pure sine wave output suitable for sensitive electronics and motor loads.
- SCHUKO (CEE 7/4) output socket provides a standard European 230V AC connection directly on the unit.
- VE.Direct communication port allows monitoring and configuration via compatible Victron devices, including the VictronConnect app over USB or Bluetooth adapter.
- Wide input voltage range with automatic low battery shutdown and restart to protect the connected battery.
- High-frequency switching design results in a compact, lightweight unit weighing 2.6 kg.
- Overload and short-circuit protection with automatic recovery.
- Temperature-controlled cooling fan reduces noise at low loads.
Product Overview
The Phoenix 12/250 converts 12V DC battery power to a clean 230V AC pure sine wave output. Pure sine wave output is important because it replicates grid-quality power, making the inverter compatible with inductive loads such as small motors and fans, as well as sensitive electronics that would be damaged or perform poorly on a modified sine wave supply.
The VE.Direct port is a key practical feature for installers. It enables direct connection to Victron monitoring equipment such as the Color Control GX or Cerbo GX, and allows configuration and live data readout via the VictronConnect app when used with a VE.Direct to USB or Bluetooth Smart dongle. This makes the unit straightforward to integrate into a wider Victron system.
At 250VA, this inverter is suited to powering individual loads rather than whole-system supply. Typical applications include laptop charging, LED lighting circuits, small power tools, and low-wattage appliances in vans, boats, cabins or as a small UPS-style backup. The SCHUKO socket means no additional wiring to an output terminal block is required for basic installations.
Technical Specifications
| Parameter | Value |
| SKU | PIN121251200 |
| Nominal DC Input Voltage | 12V |
| Continuous Output Power | 250VA |
| AC Output Voltage | 230V AC |
| Output Waveform | Pure sine wave |
| Output Socket | SCHUKO (CEE 7/4) |
| Communication | VE.Direct |
| Weight | 2.6 kg |
| GTIN | 8719076045205 |
Applications
- Van and campervan conversions requiring a 230V AC supply from a 12V leisure battery.
- Marine installations on small vessels needing a compact inverter for low-power AC loads.
- Off-grid cabins and garden buildings with a 12V battery system.
- Small backup power supply for routers, lighting or low-wattage appliances.
- Integration into a Victron monitoring system via VE.Direct for remote data logging.
What Is Included
- 1x Victron Phoenix Inverter 12/250 230V VE.Direct SCHUKO unit
Installation Notes
This inverter must be connected to a 12V DC battery system using appropriately rated DC cabling and fusing. DC wiring should be kept as short as possible to minimise voltage drop and heat. The unit is not grid-tied and does not require G98 or G99 compliance. Installation should be carried out by a qualified electrician or competent person familiar with DC battery systems. Ensure adequate ventilation around the unit to allow the cooling fan to operate correctly. Do not install in a sealed enclosure without provision for airflow.
