Description
xPhoenix Inverter 48/1200 230V VE.Direct SCHUKO
The Victron Phoenix Inverter 48/1200 is a pure sine wave DC-to-AC inverter designed for off-grid and backup power applications. It converts 48V DC battery power to 230V AC at 1200VA continuous output, with a SCHUKO socket for direct appliance connection. VE.Direct connectivity allows monitoring and configuration via Victron's software ecosystem.
Key Features
- 1200VA continuous output with pure sine wave AC, suitable for sensitive electronics and motor loads.
- 48V DC input with VE.Direct port for direct communication with Victron monitoring devices and the VictronConnect app.
- SCHUKO output socket provides a standard European plug connection for immediate appliance use without additional wiring.
- High peak power capacity handles inrush currents from motors, compressors and similar loads.
- Comprehensive protection including over-temperature, overload, low battery voltage shutdown and short-circuit protection.
- Low idle power consumption makes it practical for installations where the inverter runs continuously or for extended periods.
- Compact and wall-mountable design suited to vehicle, marine, off-grid cabin and backup power installations.
Product Overview
The Phoenix 48/1200 operates from a 48V battery bank and delivers a clean, stable 230V AC sine wave output. Pure sine wave output is important where the load includes variable-speed motors, medical equipment, audio equipment or any device with a switched-mode power supply. A modified sine wave inverter will cause problems with these load types; the Phoenix avoids that entirely.
VE.Direct is Victron's point-to-point serial communication interface. On this inverter it enables connection to the Victron GX device range, the VE.Direct to USB interface, or direct Bluetooth monitoring via the VE.Direct Bluetooth Smart dongle. This allows real-time monitoring of AC output, battery state and alarm conditions without additional shunts or external meters. For installers building a Victron-based system, this integration is straightforward and well-supported.
The SCHUKO socket format means the unit can be used immediately with standard European plugs. For installations requiring hardwired AC output, Victron also produces variants with terminal connections. At 6.9 kg, the unit is manageable for a single installer and includes mounting provisions for a fixed installation.
Technical Specifications
| Parameter | Value |
| SKU | PIN482121200 |
| Continuous Output Power | 1200VA |
| DC Input Voltage | 48V |
| AC Output Voltage | 230V |
| Output Waveform | Pure sine wave |
| Communication | VE.Direct |
| AC Output Socket | SCHUKO |
| Weight | 6.9 kg |
| GTIN | 8719076056911 |
Applications
- Off-grid cabins and remote buildings powered by a 48V battery bank.
- Marine and narrowboat installations requiring 230V AC from a 48V DC system.
- Vehicle conversions (campervan, expedition vehicle) with a 48V house battery.
- Backup power for sensitive equipment such as routers, NAS devices or medical apparatus.
- Telecoms and industrial enclosures needing a compact, monitored AC supply from a DC battery system.
What Is Included
- Phoenix Inverter 48/1200 230V VE.Direct SCHUKO unit
Installation Notes
This inverter operates at 48V DC and must be connected to a correctly fused and rated DC supply. DC wiring at this current level carries significant fault energy; connections should be made by a qualified electrician or experienced installer. The unit is not grid-tied and does not require G98 or G99 notification. For any installation in a domestic or commercial property, work on the AC side must comply with BS 7671 wiring regulations. Ensure the battery bank is appropriately sized for the intended load and that DC cable sizing accounts for voltage drop at full output current.
