xVictron Phoenix Smart IP43 Charger 24V/16A (3 Outputs) 230V
The Victron Phoenix Smart IP43 Charger 24/16(3) is a three-output, mains-powered battery charger designed for 24V battery banks. It is suited to professional installers, marine and vehicle applications, and off-grid systems where multiple battery banks need to be charged simultaneously from a single unit. This product is available while stocks last.
Key Features
- 24V output at 16A total charge current across three independent outputs.
- IP43 rated enclosure, providing protection against solid objects over 1mm and water spray up to 60 degrees from vertical.
- Bluetooth connectivity via the VictronConnect app for monitoring and configuration without additional hardware.
- Seven-stage adaptive charging algorithm with battery-safe absorption and float management.
- Compatible with lead-acid battery types including AGM, Gel, and flooded, as well as lithium (LiFePO4) batteries.
- 230V AC mains input, suitable for standard UK and European single-phase supply.
- Three separate outputs allow simultaneous charging of a main battery bank and two auxiliary banks.
Product Overview
The Phoenix Smart IP43 Charger uses a microprocessor-controlled adaptive charging algorithm. The charger monitors battery response during the absorption phase and adjusts the charge time accordingly, which reduces stress on the battery and extends service life compared to fixed-time charging. The seven-stage process covers bulk, absorption, float, storage, and a periodic equalisation cycle for lead-acid types.
Bluetooth integration means the charger can be configured and monitored directly from a smartphone or tablet using the VictronConnect app. Charge parameters, battery type presets, and real-time voltage and current data are all accessible without connecting a separate interface cable. This is particularly useful in installations where the charger is mounted in an enclosed or hard-to-reach location.
The three-output design is a practical feature for installations with separate battery banks, such as a starter battery and a service bank on a vessel or vehicle. Each output is independently managed, so the charger allocates current based on the state of each connected battery rather than splitting current equally.
Specifications
- SKU: PSC241653085
- Output voltage: 24V
- Charge current: 16A
- Number of outputs: 3
- AC input: 230V
- IP rating: IP43
- Weight: 3.7 kg
- GTIN: 8719076041931
Applications
- Marine vessels with separate starter and service battery banks.
- Motorhomes and coaches requiring simultaneous charging of multiple 24V banks.
- Off-grid cabins and sheds with mains hook-up for battery maintenance.
- Commercial vehicles with auxiliary 24V battery systems.
- Workshop or yard charging stations for 24V equipment batteries.
What Is Included
- 1x Victron Phoenix Smart IP43 Charger 24/16(3) 230V
Installation Notes
This charger requires a 230V AC mains supply. Installation should be carried out by a qualified electrician familiar with battery systems and DC wiring. Ensure the AC supply is protected by an appropriately rated circuit breaker and that DC output cabling is sized correctly for the charge current and cable run length. Verify battery chemistry compatibility before selecting a charge profile. This product is available until current stock is exhausted and is not being replenished.
