xVictron SmartSolar MPPT 250/85-Tr VE.Can — SCC125085411
The Victron SmartSolar MPPT 250/85-Tr VE.Can is a high-capacity solar charge controller designed for large off-grid, marine and commercial installations. It accepts a maximum PV open-circuit voltage of 250V and delivers up to 85A of charge current, making it suited to substantial battery banks where precise, efficient charging is critical. Built-in Bluetooth and VE.Can connectivity allow full integration into Victron system networks.
Key Features
- Maximum PV input voltage of 250V open-circuit, supporting large series-connected panel strings.
- 85A maximum charge current output, suitable for high-capacity battery banks in 12V, 24V and 48V systems.
- VE.Can port enables direct integration with Victron GX devices, Cerbo GX and other CAN-bus compatible equipment for full system monitoring and control.
- Built-in Bluetooth allows wireless configuration and monitoring via the VictronConnect app on iOS and Android without additional hardware.
- Tr (screw terminal) design provides secure, reliable cable termination for fixed installations.
- Advanced MPPT algorithm continuously tracks the maximum power point, maintaining high conversion efficiency across varying irradiance and temperature conditions.
- Supports multiple battery chemistries including flooded lead-acid, AGM, gel and lithium, with configurable charge profiles.
- Integrated load output control and programmable relay for system automation and load management.
Product Overview
The 250/85-Tr VE.Can sits at the upper end of Victron's SmartSolar MPPT range. The 250V maximum PV voltage rating allows longer panel strings in series, reducing cable losses and simplifying wiring in larger arrays. At 85A output, a single unit can deliver up to 4,080W of charge power into a 48V battery bank, making it a practical choice for off-grid cabins, large boats, vehicles and commercial installations where a single high-current controller is preferable to paralleling smaller units.
VE.Can connectivity is the key differentiator at this level. Unlike models with only VE.Direct, the VE.Can interface allows the controller to communicate directly with a GX device (such as the Cerbo GX or Venus GX) over a CAN-bus network, enabling real-time data logging, remote monitoring via VRM, and coordinated system control alongside other Victron components. Multiple VE.Can devices can be daisy-chained on the same bus, which is particularly useful in larger systems with parallel charge controllers or battery monitors.
The built-in Bluetooth removes the need for a separate dongle during commissioning. Installers can configure charge voltages, battery type, absorption time and load output behaviour directly from a phone or tablet. Once installed, the same app provides live power flow data and historical yield graphs without requiring a GX device to be present on site.
Technical Specifications
| Parameter | Value |
| SKU | SCC125085411 |
| Maximum PV open-circuit voltage | 250V |
| Maximum charge current | 85A |
| Supported battery voltages | 12V, 24V, 48V |
| Maximum PV power (12V battery) | 1,150W |
| Maximum PV power (24V battery) | 2,300W |
| Maximum PV power (48V battery) | 4,080W |
| Connectivity | VE.Can, Bluetooth (built-in) |
| Terminal type | Screw terminals (Tr) |
| Weight | 4.5 kg |
| GTIN | 8719076050896 |
Applications
- Large off-grid residential and cabin systems with 48V battery banks and high panel counts.
- Marine and narrowboat installations requiring CAN-bus integration with chart plotters or Victron GX monitoring systems.
- Commercial vehicle and motorhome builds where a single high-current controller simplifies the electrical architecture.
- Agricultural and rural off-grid sites with substantial energy storage and remote monitoring requirements via VRM.
- Parallel installations alongside a second SmartSolar MPPT unit on a shared VE.Can bus for very large arrays.
What Is Included
- Victron SmartSolar MPPT 250/85-Tr VE.Can charge controller (SCC125085411)
Installation Notes
Installation should be carried out by a qualified electrician or accredited solar installer. PV string voltage must be calculated at the lowest expected ambient temperature to ensure open-circuit voltage does not exceed the 250V maximum under any conditions. Battery and PV cabling must be correctly rated for the maximum current. VE.Can wiring requires 120-ohm termination resistors at each end of the bus; Victron supplies these separately. For any grid-connected or G98/G99-notifiable system, consult your DNO and ensure all relevant compliance requirements are met before commissioning.
